SIGMA 18-35mm F1.8 DC HSM

Introducing a newlarge-aperture APS-C format...

Explore Our Products

SIGMA 18-35mm F1.8 DC HSM

SIGMA 18-35mm F1.8 DC HSM

Megapixel

24.6MP

Brust Speed

18fps

Stills base ISO

100/640

Weight (Battery & card)

422gm

Crop Zoom function

No

Autofocus

Contrast

Featured

The ultimate ultra-fast wide-angle prime lens for DSLRs

This full-frame optic was the first full-frame 20mm prime ever built with an F1.4 aperture, making it one of the most desirable lenses on the market for astrophotography, weddings and interiors. Not only does the lens allow four times the amount of light on the sensor than an F2.8 lens with the same ISO and shutter speed, but the wide-aperture also creates a very shallow depth-of-field for pronounced subject separation when shooting portraits or closer-up objects.

This full-frame optic was the first full-frame 20mm prime ever built with an F1.4 aperture, making it one of the most desirable lenses on the market for astrophotography, weddings and interiors. Not only does the lens allow four times the amount of light on the sensor than an F2.8 lens with the same ISO and shutter speed, but the wide-aperture also creates a very shallow depth-of-field for pronounced subject separation when shooting portraits or closer-up objects.

Gallery

Check our image gallery

Lorem Ipsom

Lorem Ipsom

Lorem Ipsom

Lorem Ipsom

1

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

2

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

3

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

4

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

5

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

6

Precision brass mount with seal

Weighing less than 430g each, including battery and SD card, the fp and fp L are exceptionally portable, but deliver a powerful and versatile feature-set for both stills and video.

Tech Specs

Specifications in detail

Supplied Accessories

FRONT CAP LCF-77mmⅢ

Barcode No.
00-85126-93001-1

REAR CAP LCR Ⅱ

* The image is for SIGMA.

  • L-Mount

    00-85126-93725-6

    Sony E-mount

    00-85126-92987-9

LENS HOOD LH878-03

Barcode No.
00-85126-93848-2

Separately Sold Accessories

WR CERAMIC PROTECTOR 72mm

With many applications in aerospace and other industries, glass ceramics is an extremely tough type of crystallized glass that serves as the foundation for Clear Glass Ceramics. While featuring the high transmittance required of optical devices, this advanced new material combines greater hardness than chemically strengthened glass and greater flexibility than sapphire crystal glass. These qualities make Clear Glass Ceramics the ideal material for protective lens filters.

* Thinner frame wide type.

Barcode No.
00-85126-93181-0

PROTECTOR 72mm

Protector is developed to protect the lens surface from dirt and dust as well as scratches. It is an ideal filter for regular use as it is completely colorless so does not affect color reproduction.

* Thinner frame wide type.

Barcode No.
00-85126-93108-7

WR PROTECTOR 72mm

Water-repellent, Antistatic type. Protector is developed to protect the lens surface from dirt and dust as well as scratches. It is an ideal filter for regular use as it is completely colorless so does not affect color reproduction.

* Thinner frame wide type.

Barcode No.
00-85126-93095-0

WR UV FILTER 72mm

UV Water-repellent, Antistatic type. UV filter prevents the bluish tone that generates when the weather is fine, by absorbing ultraviolet rays. It is effective in most situations, such as landscape, portrait and general photography on a sunny day. It is also an ideal filter for regular use as it is completely colorless so does not affect color reproduction.

* Thinner frame wide type.

Barcode No.
00-85126-93069-1

WR CIRCULAR PL FILTER 72mm

PL Water-repellent, Antistatic type. Circular PL filter removes the reflection of water surface and glass windows, and increases the contrast in landscape photography.

* Thinner frame wide type.

Barcode No.
00-85126-93082-0

USB DOCK UD-11

  • L-Mount

    00-85126-87869-6

MOUNT CONVERTER MC-11

The SIGMA MOUNT CONVERTER MC-11 allows you to use your SIGMA SA mount and SIGMA EOS mount interchangeable lenses with the Sony E-mount camera body.

SIGMA SA-E
SIGMA SA-mount
00-85126-93251-0
CANON EF-E
Canon EF mount
00-85126-93250-3

MOUNT CONVERTER MC-21

The SIGMA MOUNT CONVERTER MC-21 allows SIGMA SA mount and SIGMA’s CANON EF mount interchangeable lens owners to use their lens investment on L-Mount camera bodies.

SIGMA SA-L
SIGMA SA-mount
00-85126-93724-9
CANON EF-L
Canon EF mount
00-85126-93723-2

For Support Kindly call us or eMail us

Email: saleschennai@shetalacamera.com
Tel: +91 44 -42125148/58/68
Mobile: +91 98005 98005

Diffraction MTF

Geometrical MTF

Distortion







Lens Construction



  • Lens Construction

    17 elements in 12 groups

    Angle of View

    • 76.5° – 44.2°

    Number of Diaphragm Blades

    9 (Rounded diaphragm)

    Minimum Aperture

    F16

    Minimum Focusing Distance

    28cm/11.0in.

    Maximum Magnification Ratio

    1:4.3

    Filter size

    φ72mm

    Dimensions (Diameter × Length)

    • SIGMA SA-Mount
      φ78mm × 121mm / φ3.1in. × 4.8in.
    • *The length of a lens is measured from the filter surface to its mount.

    Weight

    • SIGMA SA-Mount
      810g / 28.6oz.

    Edition Number

    A013

    Supplied Accessories

    Case and Petal Type Lens Hood (LH780-06) included.

    Corresponding AF Mounts / Barcode No.

    • SIGMA SA-Mount
      00-85126-21056-4
    • Nikon F Mount
      00-85126-21055-7
    • Canon EF Mount
      00-85126-21054-0
    • Sony A-Mount
      discontinued
    • Pentax Mount
      discontinued

    Technologies

This lens features the latest SIGMA technologies to offer F1.8 throughoutthe zoom range and ultimate performance

Exemplifying SIGMA’s design know-how and advanced production technologies,
this innovative lens offers the highest level of craftsmanship.

To develop a large aperture zoom lens with a maximum aperture of F1.8, it was necessary to solve a variety of technical challenges. As the f-number decreases, so does the depth of focus, making it extremely difficult to minimize spherical aberration, axial chromatic aberration, astigmatism and field curvature. To minimize astigmatism across the zoom range, SIGMA leveraged its extensive experience in reducing optical aberrations and designing advanced structural elements. SIGMA gained this know-how when it developed such super wide angle zoom lenses as the SIGMA12-24mm F4.5-5.6 II DG HSM and SIGMA 8-16mm F4.5-5.6 DC HSM. Ongoing technological innovation at SIGMA’s Aizu Factory has also contributed to further enhancements in lens production. Advanced production technologies have made possible a large-diameter molded glass aspheric lens, which teams up with SLD (Special Low Dispersion) glass elements to optimize power distribution and minimize axial chromatic and spherical aberration and field curvature. Thanks to its hard-earned knowledge of lens design and advanced lens manufacturing techniques, SIGMA has succeeded in creating a lens that offers F1.8 throughout the zoom range, as well as exceptional image quality at wide open aperture.

Description

Image quality until now found only in a fixed focal length lens. The definitive large-aperture APS-C format standard zoom lens.

A large-aperture fixed focal length lens is great for achieving expressive bokeh effects and enjoying ultra-high optical performance. On the other hand, photographers often need to change the angle of view to properly capture the scene that presents itself. To solve this decades-long dilemma, SIGMA proudly introduces the 18-35mm F1.8 DC HSM next-generation large-aperture APS-C format standard zoom lens for digital SLR cameras. Taking on the challenge of creating the world’s first* wide-aperture lens to offer an aperture of F1.8 throughout the zoom range, SIGMA has succeeded in creating a zoom lens that offers the same high optical performance of a fixed focal length lens. These outstanding performance characteristics are especially apparent in an APS-C format camera, since it has a slightly greater depth of focus than a full-frame camera. This is a revolutionary lens that overturns preconceptions while expanding the range of photographic expression.



Additional information

MOUNT

CANON, NIKON

Made in Aizu

All Sigma cameras and lenses are designed, manufactured and assembled at our sole factory at Aizu in Japan. This domestic production model is unusual in today’s industry, with most imaging companies opting to outsource to other countries to reduce costs. But SIGMA believes that keeping virtually all manufacturing, processing and assembly in Aizu is essential for creating innovative, carefully thought-out and impeccably constructed products that meet the high standards demanded by professional photographers and film-makers around the world.

Sigma chose Aizu as its main production base in the early 1970s. Situated at the base of Mount Bandai in the Fukushima Prefecture, about four hours’ drive north of Tokyo, Aizu has an
