SIGMAfp

Deconstruction of digital camera.- the starting point and journey of...

Buy Now

43.3mm

megapixels

FF

sensor

Contrast

autofocus

18 fps

burst speed

422g

in weight

4K UHD

video

EVF

optional

100/640

stills base ISO

15+

Color Modes

£1600

inc. VAT

Specification Accessories Buy Now

Tech Specification

LI-ION BATTERY BP-51

This dedicated battery is included as standard equipment for the SIGMA fp series and SIGMA dp Quattro series.

Barcode No.
00-85126-93039-4

CONVERTER CAP LCT-Ⅱ TL

This is a dedicated body cap for SIGMA fp series.

Barcode No.
00-85126-93732-4

NECK STRAP FOR fp

This is a dedicated neck strap for SIGMA fp series.

Barcode No.
00-85126-93760-7

STRAP HOLDER SH-11 (2 pcs.)

This is a dedicated strap holder for SIGMA fp series. It will be sold as a set of two.

Barcode No.
00-85126-93840-6

HOT SHOE UNIT HU-11

A removable hot shoe unit with a mechanism to prevent HDMI cable from coming off.

USB AC ADAPTER UAC-21

This is an AC adapter supplied with the SIGMA fp L.

USB CABLE SUC-41

This is an USB cable supplied with the SIGMA fp L.

Separately Sold Accessories

HAND GRIP HG-11

A grip designed exclusively for the SIGMA fp series for an improved hold.

Barcode No.
00-85126-93733-1

LARGE HAND GRIP HG-21

A large grip that further enhances a secure hold, designed exclusively for the SIGMA fp series.

Barcode No.
00-85126-93734-8

LCD VIEWFINDER LVF-11

A viewfinder designed exclusively for use with the SIGMA fp series. Mounted over the LCD monitor, it cuts out extraneous light. It has a diopter adjustment of −2 to +1 dpt. With a 2.5x* magnification, it helps photographers to check focus and compose their shots. The specially designed, high-performance lens and advanced lens coating secure excellent visibility.
* The value of magnification was determined based on a definition commonly used for calculating the power of a magnifying glass.
* SIGMA BASE PLATE BPL-11 Supplied.

Barcode No.
00-85126-93735-5

ELECTRONIC VIEWFINDER EVF-11

An external electronic viewfinder(optional) designed exclusively for use with the SIGMA fp series. With its 0.5 inch, 3.68 M dots OLED panel, this high-resolution, high-luminance viewfinder will make you feel immersed in your photography experience more thoroughly than ever.
*The EVF-11 and the HU-11 cannot be mounted on the camera together.

Supplied Accessories

EYECUP EC-31, LARGE EYECUP EC-41, Semi-hard Case VC-07A

Barcode No.
00-85126-93904-5

BASE PLATE BPL-11

A base plate designed exclusively for the SIGMA fp series. In addition to mounting an LCD VIEWFINDER LVF-11 to the body, it can also be utilized to attach standard accessories commonly used for video shooting by using 3/8-inch threads.
* Supplied with the LCD viewfinder (LVF-11).

Barcode No.
00-85126-93736-2

CABLE RELEASE CR-41

A cable release designed exclusively for the SIGMA fp series. It comes with a φ3.5mm stereo mini plug to connect the microphone.

Barcode No.
00-85126-93737-9

BASE GRIP BG-11

When it is attached to the screw hole on the bottom surface of the camera, it allows handgrip-style of shooting. It is compact and convenient and therefore very easy to carry. The bottom part of the Base Grip BG-11 has a screw hole so that it can attach directly to a tripod.

Barcode No.
00-85126-93144-5

DC CONNECTOR CN-21

A connector that connects the SIGMA fp series to an AC adapter or external power supply source.
* Supplied with the dedicated AC adapter “AC ADAPTER SAC-7P”.

Barcode No.
00-85126-93738-6

BATTERY CHARGER BC-71

A battery charger set designed exclusively for the SIGMA fp series’ battery BP-51.

Barcode No.
00-85126-93740-9

AC ADAPTER SAC-7P

A dedicated adapter for using SIGMA fp series with a household power supply. Recommended for long-time shooting, image playback, etc.
Includes DC connector SIGMA DC CONNECTOR CN-21.

Barcode No.
00-85126-93748-5

ELECTRONIC FLASH EF-630

The high-power EF-630 flash enables TTL automatic flash metering. It has wireless flash connectivity and a high-speed synchronization function that can be used at high shutter speeds, giving photographers further scope for creative expression.

MOUNT CONVERTER MC-21

The SIGMA MOUNT CONVERTER MC-21 allows SIGMA SA mount and SIGMA’s CANON EF mount interchangeable lens owners to use their lens investment on L-Mount camera bodies.

MOUNT CONVERTER MC-31

The new MOUNT CONVERTER MC-31 allows you to use your PL mount interchangeable lenses with the L-Mount camera body, such as SIGMA fp / SIGMA fp L.

Supplied Accessories

Cap, Support foot, Hex wrench, Screwdriver,Mount lock screw, L-Mount shim

Barcode No.
00-85126-93819-2

For Support Kindly call us or eMail us

Email: saleschennai@shetalacamera.com
Tel: +91 44 -42125148/58/68
Mobile: +91 98005 98005

N.A

Interchangeable-lens Mirrorless Type Digital Camera

SD, SDHC, SDXC memory card (UHS-Ⅱ supported) , Portable SSD (USB 3.0 connection, USB bus power supported)

L-Mount

35 mm full-frame (35.9 mm x 23.9 mm) Back-illuminated Bayer CMOS sensor

Approx. 24.6 MP / Approx. 25.3 MP

3:2

RGB Primary color filter

Lossless compression RAW(DNG) data 12 bit,14 bit / JPEG(Exif2.3), RAW(DNG)+JPEG:recording is possible

[21:9] / [16:9] / [3:2] / [A Size (√2:1) ] / [4:3] / [7:6] / [1:1]

*() In DC Crop Mode

HIGH : 6,000×4,000 (3,840×2,560)
LOW : 3,008×2,000 (1,920×1,280)

HIGH : 6,000×2,576 (3,840×1,648)
MED : 4,240×1,824 (2,736×1,168)
LOW : 3,008×1,288 (1,920×824)

HIGH : 6,000×3,376 (3,840×2,160)
MED : 4,240×2,392 (2,736×1,536)
LOW : 3,008×1,688 (1,920×1,080)

HIGH : 6,000×4,000 (3,840×2,560)
MED : 4,240×2,832 (2,736×1,824)
LOW : 3,008×2,000 (1,920×1,280)

HIGH：5,664×4,000 (3,616×2,560)
MED：4,000×2,832 (2,560×1,824)
LOW：2,832×2,000 (1,808×1,280)

HIGH：5,344×4,000 (3,408×2,560)
MED：3,776×2,832 (2,416×1,824)
LOW：2,672×2,000 (1,712×1,280)

HIGH：4,960×4,000 (3,184×2,560)
MED：3,520×2,832 (2,272×1,824)
LOW：2,480×2,000 (1,584×1,280)

HIGH：4,000×4,000 (2,560×2,560)
MED：2,832×2,832 (1,824×1,824)
LOW：2,000×2,000 (1,280×1,280)

Equivalent to approx.1.5times the focal length of the lens (for 35 mm cameras)

sRGB, Adobe RGB

CinemaDNG（8 bit, 10 bit, 12 bit）/ MOV：H.264 （ALL-I, GOP）

Linear PCM (2 ch 48 kHz / 16 bit)

3,840 x 2,160 (UHD 4K) / 23.98 p, 24 p, 25 p, 29.97 p
1,920 x 1,080 (FHD) / 23.98 p, 24 p, 25 p, 29.97 p, 48 p, 50 p, 59.94 p, 100 p, 119.88 p

Up to 2 hours

SD Card (UHS-II) : UHD 8 bit 25 p or less, FHD 12 bit 59.94 p or less
Portable SSD : UHD 12 bit 29.97 p or less, FHD 12 bit 100 p or less, FHD 8 bit 119.88 p or less

4:2:2 8 bit
12 bit RAW :External recorder record : ATOMOS Ninja V, Blackmagic Video Assist 12G supported

Linear PCM (2 ch 48 kHz/16 bit)

4,096 x 2,160 (DCI 4K) / 24 p　* Only for RAW output
3,840 x 2,160 (UHD 4K) / 23.98 p, 24 p, 25 p, 29.97 p
1,920 x 1,080 (FHD) / 23.98 p, 24 p, 25 p, 29.97 p, 48 p, 50 p, 59.94 p, 100 p, 119.88 p

Contrast detection system, Single AF, Continuous AF (with moving object prediction function), Manual Focus

-5 to 18 EV (F1.4:ISO 100) / Auto, 49-point selection mode, Free Move mode, Face/Eye Detection AF mode, Tracking AF mode

Half-press the shutter button, or press the AEL button (setting change required)

AF+MF, MF Assist, MF Guide, Focus Peaking, Release Focus Function, AF-ON, Quick AF, Pre-AF, AF during Image Magnification

Evaluative, Spot, Center Weighted Average

-5 to 18 EV (50 mm F1.4:ISO 100)

(P) Program AE (Program Shift capable), (S) Shutter Speed Priority AE, (A) Aperture Priority AE, (M) Manual

(P) Program AE, (S) Shutter Angle Priority AE, (A) Aperture Priority AE, (M) Manual

[Still]
ISO 100,640
[Cine]
CinemaDNG 12 bit / HDMI RAW:ISO 100, 3200
MOV / CinemaDNG 10 bit, 8 bit, HDMI 4:2:2 8 bit:ISO 100, 640

ISO 100-25600 / Expanded sensitivity ISO 6, 12, 25, 50, 51200, 102400

±5 EV (in 1/3 stop increments) : ±3 EV at movie recording

Half-press the shutter button, or press the AEL button (setting change required)

3 shots / 5 shots stage exposure 3EV (1/3 Step, Standard→Underexposure→Overexposure) (Sequence changeable)

Image Stabilization System(EIS)

12 types
( Auto, Auto[Lighting Source Priority], Daylight, Shade, Overcast, Incandescent, Fluorescent, Flash, Color Temperature[50K steps], Custom 1, Custom 2, Custom 3 )

Electronic shutter

30 to 1/8,000 sec., Bulb up to 300 sec.
* Up to 1/4,000 sec. when using electronic image stabilization

2 sec. / 10 sec.

Single Capture, Continuous, Self Timer (2sec. / 10sec.), Interval Timer

High Speed:approx. 18 shots/ sec, Medium Speed:approx. 5 shots/ sec, Low Speed:approx. 3 shots/ sec.

HIGH: 12 frames, MED: 12 frames, LOW: 24 frames

TFT color LCD, Aspect Ratio 3:2, 3.15 type, Approx. 2.1M dots , Electrostatic capacitance system touch panel / Approx. 100%

–

S-TTL automatic light control, Manual, Wireless flash, Multi-emission

Red-eye Reduction / Slow Synchronization, Rear Curtain Synchronization

Max. ±3 EV in 1/3EV step increments

Max. 1/30 sec.
* 1/15 sec. or less at 14 bit RAW

Available when the HOT SHOE UNIT HU-11 (supplied with this product) is mounted. * S-TTL, Wireless support, X-sync.

15 types
(Standard, Vivid, Neutral, Portrait, Landscape, Cinema, Teal and Orange, Sunset Red, Forest Green, Powder Blue, FOV Classic Blue, FOV Classic Yellow, Duotone, Monochrome, Off )

ARRICAM / ARRIFLEX, ALEXA LF/ ALEXA Mini LF, ALEXA SXT, ALEXA Mini, AMIRA, ALEXA65, ALEXA XT

VENICE

MONSTRO 8K, HELIUM 8K, DRAGON 6K, EPIC MX 5K, GEMINI 5K, KOMODO 6K

1.33:1, 1.85:1, 2.39:1, Custom 1, Custom 2

Input (Sensor Area / Aspect Ratio) , Offset, Style (4 styles) , Line (1 to 10 px) , Color (White, Black, Red, Yellow, Green, Cyan, Blue, Magenta) , Shading

Save / Load Settings via QR code, Screenshot, Webcam, In-camera RAW development, Still image capture from recorded movie files, Cinemagraph, Fill Light, HDR shooting (Still / Cine) , Still image shooting during movie shooting

Stereo microphone, Monaural speaker

English / Japanese / German / French / Spanish / Italian / Simplified Chinese / Traditional Chinese / Korean / Russian / Dutch / Polish / Portuguese / Danish / Swedish / Norwegian / Finnish

USB3.1 GEN1 Type-C (supports Mass Stroage, Video Class(UVC), Camera Control)

Type D（Ver.1.4）

Also used as an external microphone terminal

Φ3.5 mm stereo mini jack (Plug-in power support)

Φ3.5 mm stereo mini jack (can be connected when using the dedicated ELECTRONIC VIEWFINDER EVF-11)

Dedicated terminal (with HOT SHOE UNIT HU-11 (supplied with this product) mounted)

Provided
*Although this construction allows the lens to be used in light rain, it is not the same as being waterproof.

Li-ion Battery Pack BP-51
*Internal battery charge via USB terminal available.
(the camera can not be used while charging)

Approx. 280 images

Approx. 70 min.

112.6 x 69.9 x 45.3 mm / 4.4 x 2.8 x 1.8 in.

422 g / 14.9 oz.(including battery and SD card), 370 g / 13.0 oz.(Camera body only)

32 – 104 °F / 0 – +40 °C

85 % or less (non-condensing)

Li-ion Battery Pack BP-51
Strap
STRAP HOLDER SH-11
USB AC ADAPTER UAC-11
USB CABLE (A-C) SUC-11
HOT SHOE UNIT HU-11
Body Cap
Instruction Manual
Limited Warranty
Warranty Sticker

HAND GRIP HG-11
LARGE HAND GRIP HG-21
LCD VIEWFINDER LVF-11
ELECTRONIC VIEWFINDER EVF-11
BASE PLATE BPL-11
CABLE RELEASE CR-41
BASE GRIP BG-11
DC CONNECTOR CN-21
BATTERY CHARGER BC-71
AC ADAPTER SAC-7P
STRAP HOLDER SH-11 (2pcs)

Pocketable Full-frame

Small in size, big on quality. Perfect for carrying anywhere.

As a camera that keeps the very essence of photography, the SIGMA fp is the world’s smallest and lightest* full-frame mirrorless camera.
You can take it with you anytime, anywhere—this will build a new relationship between you and a full-frame camera.

Scalable

From vintage lenses to modern gadgets, up to professional movie setup.
Creating your own style has never been so easy.

Pair it with the latest lens and accessories, or enjoy a vintage lens using an adapter. Keep it small and casual to take it out for everyday snaps, or build a full-fledged filmmaking setup.
Old and new, large and small.
Customize your fp just the way you want it, to suit what you want to do.

Seamless

Capturing your best moment. Photo or video? The choice is yours.

Change shooting modes with just a flip of a switch. The SIGMA fp goes back and forth seamlessly between video and stills, responding straight to how you like to shoot, going beyond the boundaries of style or genre.

Description

SIGMA has been questioning the genuine value of a digital camera and how can we break down manufacturer’s ideas of camera-centric hierarchies and categories.

Deconstruction is our answer after rethinking what is essential to the users. We believe a camera should be more than a tool for fulfilling rational needs of photography making, but enriching life as your inspiration.
Therefore, “how can SIGMA be the one to make this happen?”

As the answer to this question, SIGMA set itself to develop a user-oriented digital camera that reflected the idea of “how a camera can be” in a more flexible and true-to-life manner.

A camera that keeps the heart of photography.

As a result, the SIGMA fp is the new form of camera that lets creativity get in.
Because SIGMA believes keeping the essence is the key to genuinely realize the idea of giving freedom back to you.

Additional information

MOUNT	L MOUNT

SIGMAfp

43.3mm

FF

Contrast

18 fps

422g

4K UHD

EVF

100/640

15+

£1600

Tech Specification

LI-ION BATTERY BP-51

CONVERTER CAP LCT-Ⅱ TL

NECK STRAP FOR fp

STRAP HOLDER SH-11 (2 pcs.)

HOT SHOE UNIT HU-11

USB AC ADAPTER UAC-21

USB CABLE SUC-41

Separately Sold Accessories

HAND GRIP HG-11

LARGE HAND GRIP HG-21

LCD VIEWFINDER LVF-11

ELECTRONIC VIEWFINDER EVF-11

Supplied Accessories

EYECUP EC-31, LARGE EYECUP EC-41, Semi-hard Case VC-07A

BASE PLATE BPL-11

CABLE RELEASE CR-41

BASE GRIP BG-11

DC CONNECTOR CN-21

BATTERY CHARGER BC-71

AC ADAPTER SAC-7P

ELECTRONIC FLASH EF-630

MOUNT CONVERTER MC-21

MOUNT CONVERTER MC-31

Supplied Accessories

Cap, Support foot, Hex wrench, Screwdriver,Mount lock screw, L-Mount shim

Format

Type

Memory Media

Lens Mount

Image Sensor

Type

Camera Effective Pixels / Total Pixels

Aspect Ratio

Color Filter System

Still Image File Format

Image Aspect Ratio

File Size

RAW

JPEG

[21:9]

[16:9]

[3:2]

[A Size (√2:1) ]

[4:3]

[7:6]

[1:1]

Crop

Color Space

Movie Recording Format

Camera Internal Record

Movie Format

Audio Format

Record Format / Frame rate

Continuous Shooting Enable Time

Cinema DNG Memory Media Limitation

HDMI External Output

Movie Format

Audio Format

Record Format / Frame Rate

Focus

AF System / Focus Mode

AF Sensitivity Range / AF Mode

AF Lock

Other Focus Functions

Exposure Control

Metering System

Metering Range

Still Image Shooting Mode
